Description
1. It warms as it is dimmed in only 2 wires. Dim-to-Warm concept is to dim CCT from 3000K to 1800K while its brightness is dimmed from 100% to 3% (vary according to LED driver or controller) synchronously and smoothly, perfectly simulating the warmth and dimming curve of incandescent and halogen lamp, which create a comfortable and natural lighting performance.
2. Direct dimming with PWM (Pulse-Width Modulation) output type of driver, no remote controller, no receiver, no battery, simple and convenient wiring.
3. High-density design with both warm white and cold white in 224LED/M, perfectly to get linear performance while fixing into aluminum profile.
4. Flexible choice on LED specification combination with seperated LEDs for two CCTs.
5. Color mixing effect is comparable to the 2in1 LED with two LEDs mounted closely.
|
Model No.
|
HP-TW28N224-24
|
||||
|
Power
|
20W/m
|
||||
|
PCB width
|
10mm | ||||
|
Lumen output (4000K)
|
2300 Lm/m CRI 80+
1830 Lm/m CRI 90+
1700 Lm/m CRI 95+
1600 Lm/m CRI 98+
|
||||
|
MaxRun
|
5m | ||||
|
LEDs/m
|
2835 224LEDs/m
|
||||
|
Cut Length
|
62.5mm(7+7LEDs)
|
||||
| CRI(White) | CRI80+~98+ | ||||
| CCT/Color | 2400K+6500K | ||||
| Voltage | 24V DC | ||||
| Dimmable |
Yes (PWM, DALI, 0/1-10V, Triac)
|
||||
| IP Rating | IP20 | ||||
|
Ambient temp.
|
-35°C ~ 50°C
|
||||
|
Beam Angle
|
120°
|
||||
|
Strip length/reel
|
0.5m ~ 50m
|
||||
|
Lifespan
|
50,000Hrs
|
||||
